Overview

Distance Measurement measures the distance between two points on an avatar or pattern.

Location

3D View > Right-click > Distance Measurement

Operation Method

1. Click on the avatar or pattern to specify the starting point.
   • Hold the Shift key to display reference axes in the 3D space, allowing you to measure horizontal or vertical distances.
2. Click again on the avatar or pattern to specify the next point and check the distance.
3. Select the measurement line in the 3D View to check its length. The length is displayed in the unit set by the user.
   • To delete a measurement line, select it and press the Delete key.
